Call for Price

In Stock

Long Distance Wiegand Reader

Compare

Read range up to 12 meters (adjustable)
• Read Sensitivity: Line polarization read mode
• Wiegand 26-Bit (Can change to 34-Bit via software)
• Two working mode: Trigger read & Always read(Default)
• Comes with the mounting plate
• Weatherproof (IP66)
• Maximum Cable Distance: 100m
• Multiple label recognition
• Wide application: Vehicle management, Personnel management and  Goods management





Technical Specifications
Model UHF1-5E,UHF1-5F UHF1-10E,UHF1-10F
Dimension 260*260*65(mm) 445*445*70(mm)
Reading distance Up to 6 meters (adjustable) Up to 12 meters (adjustable)
communication interface Wiegand 26(Default) /Wiegand 34, USB
Frequency 902Mhz – 926Mhz, 865MHz – 868MHz
Shell Material Antenna Panel:ABS Engineering Plastics; Back Cover:Aluminum Shell
Working Voltage 9~12V DC
Working Current 150mA(Always Read)
Working Temperature -20 °C – 60 °C
Interface Protocol EPC global UHF Class 1Gen 2/ISO 18000-6c
Multiple tags identification <100
Working mode Always read(Default) /Trigger read
I/O Interface Supports external trigger
Maximum power consumption <3W (RF output 26dBm,multiple tags), <2W (RF output 26dBm,Sigle tags)
