Call for Price

In Stock

2MP HD 4 in 1 Camera

  • IR distance: 20-30m


  • 3D DNR, DWDR
  • Lightning Protection up to 6KV
  • AHD/TVI/CVI/CVBS video output
  • IP67 ingress protection
  • Video Linkage with Access Control System (BioSecurity 3.0)


Technical Specifications
 Model BL-32D28L BL-32D38L
Image Sensor 1/2.7″ 2MP CMOS
Efecitive Pixels 1920*1080
Shutter Time 1/25s~1/50,000s (PAL); 1/30s~1/60,000s (NTSC)
Image System PAL/NTSC
Video Frame System 1080P@25fps (PAL); 1080P@30fps (NTSC)
IR Distance 20-30m 30-50m
Lens Motorized 2.8-12mm
Lens Mount Φ14
Horizontal FOV 30°-99°
S/N Ratio ≥41dB
OSD UTC support based on DVR
AGC Support
White Balance Auto/Manual
Day & Night Auto/Manual
Video Setting Contrast/Sharpness/Color Gain/Format/DWDR/DNR
Language Multi-Language
Casing Aluminium alloy
Ingress Protection IP67
Working Environment -30℃ ~ 60℃/Humidity 10%~90℃ RH
Power Supply DC12V±10% 1.5A
Power Consumption 3.2W MAX (IR cut off)
Dimension 186.5 (L)*71.7 (W)*84 (H)mm
Net Weight 350g
